Technical specification
- Technologies
- MRF + SRF + PDT + CRYO
- RF output frequency
- 5 MHz
- Input power
- 80 W
- MRF needle counts
- 25 / 49 / 81 pins
- SRF
- Superficial fractional RF needle
- PDT wavelength
- 650nm
- Cryo temperature
- -5C
- Display
- 15" colour TFT LCD
- Rated voltage
- AC 200V 50Hz / AC 110V 60Hz
- Dimensions
- 480 x 295 x 1060mm
- Weight
- 30 kg
- Warranty
- 12 months machine
Two needle formats share one generator: MRF penetrates for dermal work at 25, 49 or 81 pins, while the SRF head stays superficial for surface texture. The 650nm PDT head and the -5C cryo handpiece are on the same trolley, so a practitioner can run the light phase and cool the treated area without moving the client between devices. At 480mm wide and 30kg it takes a narrow footprint in a shared room.
Every order includes online operator training covering setup, treatment parameters and daily maintenance, run live with your team rather than sent as a video link. Printable parameter cards come with the machine for your intake binder. New staff can be added to training at any time, at no cost, for as long as you own the machine.
Fully insured air freight from our production line to your practice door, customs and duties prepaid — typically 12–15 days from dispatch. Consumables and cartridges ship same-day from our US warehouse. Twelve-month warranty on the machine with replacement parts supplied free, covering manufacturing and component failure.
Treatments
- Fractional RF microneedling for texture and pores
- Superficial fractional RF on thin skin
- 650nm PDT and post-treatment cryo cooling
